Metra 99-9714 Double DIN Car Stereo Dash Kit for 2014 - and Up Harley Davidson Electra Glide, Street Glide, Road Glide
Expert Knowledge
Talk to a specialist
- Fits 2014 - and Up Harley Davidson Electra Glide, Street Glide, or Road Glide Motorcycles
- Single DIN Radio Provision for easy installation of car radios
- LCD info screen that provides information from the bike
- Handlebar control interface
- Includes an electronic antenna
Metra 99-9714 Double DIN Car Stereo Dash Kit for 2014 - and Up Harley Davidson Electra Glide,Street Glide,Road Glide
-
Features:
- Fits 2014 - and Up Harley Davidson Electra Glide, Street Glide, or Road Glide Motorcycles
- Single DIN Radio Provision for easy installation of car radios
- LCD info screen that provides information from the bike about personalization settings
- Handlebar control interface. This allows the handlebar audio controls to continue working with an aftermarket radio
- Includes an electronic antenna that can be installed in the fairing so the factory rear mounted antenna mast can be removed and a factory antenna cable adapter
- Includes interface for stereo wiring connections for complete plug and play
- Uses high level speaker outputs for speaker connections
- High-grade ABS plastic construction
- Factory style fine texture
- Painted to match Motorcycle's factory center console trim
- Metra Install kits are manufactured from OEM quality ABS plastic designed to leave no gaps between the dash and the kit.
- Instruction Manual - Metra 99-9714 Double DIN Car Stereo Dash Kit
-
Kit Components:
- A) Radio housing
- B) Radio brackets
- C) LCD screen
- D) LCD back plate
- E) (10) #8 x 3/8” Phillips screws
- Axxess interface
-
Tools Required:
- Panel Removal tool
- Wire Crimper
- Crimp connectors
- Digital volt meters
- Phillips Screwdriver
- Socket wrench
- Connections:
- Yellow - 12V Constant
- Red - 12V Accessory
- Black - Ground
- Orange - Dash Light Dimmer/Illumination
- Green - Left Rear Speaker (+)
- Green with Black Stripe Left Rear Speaker (-)
- White - Left Front Speaker (+)
- White with Black Stripe - Left Front Speaker (-)
- Purple - Right Rear Speaker (+)
- Purple with Black Stripe - Right Rear Speaker (-)
- Gray - Right Front Speaker (+)
- Gray with Black Stripe - Right Front Speaker (-)
-
Vehicle Applications:
- 2014 - and Up Electra Glide
- 2014 - and Up Street Glide
- 2014 - and Up Road Glide
Harley Davidson
| Manufacturer | Metra |
|---|---|
| Part Number | 99-9714 |
| Chassis Size | Single DIN |
| Color | Black |
| Warranty | 1 Year |
| Vehicle Year | 2014, 2015, 2016, 2017, 2018 |
| Vehicle Brand | Harley Davidson |
| Vehicle Model | Electra Glide, Road Glide, Street Glide |
| UPC Code | 086429335114 |
| Return period | 30 days |
| Exchange period | 30 days |
Car stereo installation
We show you the complete process of installing a Pioneer Double DIN car stereo in a Chevy truck. The in-depth video shows the installation of the interface, and steering wheel control.
Stereo Installation Basics
Let's start with the basics of replacing your car stereo receiver. In out first video we demonstrate how to crimp or solder your wiring, mount your new receiver to your dash kit and prepare everything for an installation in your vehicle.
Wiring Harnesses Explained
What do all of the wire colors mean? Aftermarket manufacturers have made car stereo receiver installation an easier process by using a standardized wire color scheme. We walk you through what each individual wire does, this way if you have an installation that doesn't perform properly you will have the resources to begin troubleshooting your installation.
