Discontinued - Power Acoustik CPT1-3200D Crypt Series Single Channel 3200 Watt Class D Power Amplifier with Remote Bass Knob

Discontinued - Power Acoustik CPT1-3200D Crypt Series Single Channel 3200 Watt Class D Power Amplifier with Remote Bass Knob

Discontinued - Power Acoustik CPT1-3200D Crypt Series Single Channel 3200 Watt Class D Power Amplifier with Remote Bass Knob

More Views

Item sku:31124
Power Acoustik

Overall Rating 0 (Based on 0 reviews)

Would you recommend this to a friend?

Write a review

Power Acoustik CPT1-3200D Product Highlights

Discontinued - Power Acoustik CPT1-3200D Crypt Series Single Channel 3200 Watt Class D Power Amplifier with Remote Bass Knob

Quality Mobile Video Advantage

  • Lifetime Technical Support
  • 30-Day Return Policy - See exceptions
  • Premier Service - Call us! 800-363-0096
  • Fast Free Same Day Shipping - Over $99

Overview

Unit includes: Amp and Bass Knob

Power Acoustik CPT1-3200D Crypt Series Single Channel 3200 Watt Class D Power Amplifier with Remote Bass Knob
  • Channels: 1
  • Max Power: 3200 Watts
  • RMS @ 4 Ohms: 1000 Watts
  • RMS @ 2 Ohms: 1400 Watts
  • RMS @ 1 Ohm: 1800 Watts
  • Bridged @ 4 Ohms: N/A
  • 13" L x 9.8" W x 2.3" H

  • You asked for the Best bang for the buck we delivered it, in the all new Crypt line of amplifiers. This new chassis design incorporates new assembly techniques and shear volume production without sacrificing power and sound quality.
  • We learned some new circuit tricks that will deliver bone shattering power at even lower prices from our previous versions. The kids will love the new Dead Look or "Pirate Look" with skulls to match! Who doesnt have tattoos these days that are skull and crossbones.
  • We have included all the most popular features in this exciting new line-up including complimentary Class D amplifiers to match. This new series will drive them crazy. Everyone loves a little skull now and then!

  • Crypt Common Features
  • Extruded Aluminum Chassis
  • Black Texture Finish w/ Silver Trim & Cast Metal Badge
  • MOSFET PSU Transistors
  • Regulated PWM Power Supply
  • Three-Way Protection Circuitry (short, thermal & overload)
  • High Pass, Low Pass, and Subsonic Filters
  • Pre-Amp Outputs
  • 200mV-8V Low Level Inputs
  • 4 ga. Power & 8 ga. Speaker Terminals

  • Mono Block Features
  • 1 Ohm Load Stable Class A/B or D
  • Variable 12dB 50-250Hz HPF (1400 & 1900)
  • Variable 12dB 50-250Hz LPF
  • Variable 12dB 20-50Hz Subsonic Filter (Class D)
  • Selectable 45Hz, 6/12dB Bass Boost
  • Freqency Response: 15-150Hz
  • Signal-to-Noise Ratio: 80dB
  • Total Harmonic Distortion: .5%
  • 180o Phase Switch (Class D)
  • Direct 2 ga. Power & 8 ga. Speaker Terminals
  • Dash Mount Remote Gain Control
  • Bridged Synchronization (strap amps together for double power!)

  • 2/4 Ch. Features
  • 2-ohm Stereo, 4-ohm Bridged Stable Class A/B
  • Tri-Mode Capable
  • Fixed HPF 80Hz (2ch. models )
  • Variable 12dB 50-250Hz HPF (4ch. models)
  • Variable 12dB 50-250Hz LPF
  • Selectable 45Hz, 6/12dB Bass Boost
  • Frequency Response: 10Hz - 20kHz
  • Signal-to-Noise Ratio: 90dB
  • Total Harmonic Distortion: .01%
  • 4 ga. Power & 8 ga. Speaker Terminals

Technical Specifications

Manufacturer Power Acoustik
Part Number CPT1-3200D
Amplifier Topology Class Class AB
Number of Channels 1 Channel
Total Peak Power Output 3001 - 3500 watts
Total RMS Power Output 1000 - 1500 Watts
Amplifier Bridging Bridgable @ 4 ohms
Minimum Impedance in Bridged Mode No
Minimum Impedance in Un-Bridged Mode No
Strappable Amplifier N/A
Strappable Power Output N/A
RCA Pre-amp Audio inputs N/A
RCA Pre-amp Audio outputs No
Preamp output voltage No
Speaker level inputs No
Gain Control Yes
Bass Knob / Remote Gain Yes
Built in Crossover High-pass, Low-pass
Cooling Fan No
Color No
Warranty 1 Year
Recommended Power Wire Guage N/A
UPC Code No
