Built-in Microphone and External Microphone Ready with Optional RCB204
(2) Audio/Video Inputs (Front 3.5mm, Rear RCA)
2-Zone Entertainment: Front and Rear Separate Source Control
Rear USB Port with iPod® Direct Connect Capabilities
iPod Audio/Video Control with Optional CCA750 iPod Interface Cable
PANDORA® internet radio Station Link with USB using PANDORA App
Rear Vision Camera Composite Video Input
Built-in iGo Primo® mapping on Preloaded microSD Card
15 Million Points of Interest
Text to Speech for Street Announcements
Multi Language Display Capability (English, Spanish, French)
HD Radio Ready™ with iTunes® Tagging (Optional THD400)
SiriusXM-Ready™ (SiriusXM-Connect Vehicle Tuner)
50 Watts × 4 Built-in Amplifier
6-Channel / 4 Volt RCA Output
Subwoofer Volume Control
24-bit D/A Converter
Built-in High and Low Pass Filters
Magna Bass EX Dynamic Bass Enhancement and Parametric Equalizer
Beat EQ for Sound Adjustment
OEM Steering Wheel Remote Ready
Wireless Remote Control Included
Built-in navigation with microSD card provides excellent high-quality visual guidance in US 50 states, Canada and Puerto Rico, and easy software updates.
Interactive GUI with flick operation lets you scroll through menu pages and access functions simply by touching on their animated icons.
Built-in Parrot Bluetooth module to provide hands-free telephone communication and audio streaming, with wide-ranging compatibility.
iPod and iPhone connectivity for seamless enjoyment of your favorite audio and video content. Optional CCA750 cable is required for video playback.
Easy Navigation Map Updates : It is easy to keep the navigation system up to date. Simply download new map data from Clarion’s portal site, store them on a microSD card and insert it into the NZ502 via the front card slot. Unpleasant surprises are now avoided as navigation maps will match the real world.
Interactive GUI with Flick Operation: The NX501’s touch sensor GUI (Graphical User Interface) supports flick operation, so you can quickly scroll to another menu page. Feature icons are animated for an enhanced appearance, and they can be dragged and dropped into different positions to customize the screen.
Parrot Bluetooth offers extremely comprehensive compatibility with a variety of mobile phones. Enjoy hands-free communication using the built-in microphone and Phonebook access. Play music stored on your mobile phone with Bluetooth audio streaming. A wide range of protocols are supported: HFP/HSP/A2DP/AVRCP/PBAP/OPP. Firmware updates are possible via USB connection.
Dependent on mobile phone.
Made for iPod and Made for iPhone certified so you can enjoy the convenience of iPod/iPhone ABC Search to quickly access tunes, and simple control mode to allow operation using the iPod/iPhone controls. Album Artwork is displayed to visually enhance the interactivity.
For audio playback, please use the USB cable provided with your iPod / iPhone.
For video playback, an optional CCA750 cable is required.
2-Zone Entertainment: This allows rear seat passengers to enjoy a DVD movie or iPod Video while the front seat passengers enjoy their favorite radio station or music from a USB memory device.
Beat EQ for User Customizable Sound: In addition to providing 3 preset equalization patterns — BASS BOOST, IMPACT and EXCITE — Clarion’s Beat EQ allows you freedom to customize the level and range of the bass, midrange and treble portions of each pattern. You can adjust the sound to your liking, depending on the genre of music, for a more fulfilling listening experience.
RCA Pre-amp Audio outputs
3 Pairs (Front, Rear, Sub)
LCD Screen Size
7 inch - 8 inch
LCD Screen Brightness
16:9 Widescreen Display
Native Screen Resolution
800 x 480
Front camera input
Back up camera input
Audio Video inputs
2 Audio Video Inputs
Front mounted auxiliary input
3.5 mm audio input
Audio Video Outputs
1 Audio/Video output
Built-in DVD Player
Dual Zone Control
iPod Audio Connection
iPod Video Connection
SD Card input
Yes, SD Card
NTSC and PAL
Built in Bluetooth
Yes, Built in Bluetooth
NFC (Near Field Communication)
Radio Data Service - RDS
Text to Speech
Points of Interest
Steering Wheel Control Input
Yes, Built in control
Wireless Remote Control
