DISCONTINUED - Quality Mobile Video License Plate Back Up Camera System with 5.8" Monitor ZH58P3-SC0301

DISCONTINUED - Quality Mobile Video License Plate Back Up Camera System with 5.8" Monitor ZH58P3-SC0301

Quality Mobile Video License Plate Back Up Camera System with 5.8" Monitor ZH58P3-SC0301

More Views

Item sku:ZH58P3-SC0301
Safesight

Overall Rating 4 (Based on 5 reviews)

Would you recommend this to a friend?

Write a review

Safesight ZH58P3-SC0301 Product Highlights

  • 5.8" LCD Screen
  • Dual Video Input for Additional Camera or Video Source
  • License Plate Camera
  • Built in IR for Night Vision
  • Camera can be Tilted

Quality Mobile Video Advantage

  • Lifetime Technical Support
  • 30-Day Return Policy - See exceptions
  • Premier Service - Call us! 818-242-9461
  • Fast Free Same Day Shipping - Over $99

Buy everything you need as a package and SAVE!

Overview

Unit includes: 5.8 inch headrest monitor, Headrest shroud, Wiring harness, Remote control, Pedestal stand, and Instruction manual

Quality Mobile Video ZH58P3 5.8 inch LCD Monitor With Headrest Shroud & Universal Stand features:

  • 5.8" TFT LCD Stand Monitor
  • PAL/NTSC Compatible
  • Brightness: 250Cd/M2
  • High Resolution: 800 X 480
  • Trigger wire for auto turn on when vehicle is placed in reverse
  • 2 Video Inputs
  • Power Supply: 12V DC
  • Headrest Shroud & Universal Stand
  • 1/4 x 20 thumb screw nut embedded in bottom for various mounts
  • Slide track in back for various mounts
  • Dimensions with shroud: 5 1/4" (H) X 6 15/16" (W) X 1 1/8" (D)
  • Dimensions without shroud: 4 3/8" (H) X 6 1/16" (W) X 1" (D)


Unit includes: Back up camera, Wiring harness, and Instruction manual

Quality Mobile Video SC0301 License Plate Mount Rear View Camera features:
  • Resolution: 380 TV lines x 60 fields
  • Image sensor: OV 7910 Color CMOS
  • Lens: 6mm 92°
  • Low light illumination: 1.5 Lux @ F1.2
  • Video output: RCA 1.0 @ 75Ω
  • Power supply: DC 12V > 75Ω
  • Auto switch PAL/NTSC
  • Temperature: -10–50°C
  • Camera dim: 1.3" (H) x 8" (W) x 1.2" (D)

Technical Specifications

Manufacturer Safesight
Part Number ZH58P3-SC0301
LCD Screen Size 5 inch - 6 inch
Native Screen Resolution 800 x 480
Widescreen Display 16:9 Widescreen Display
LCD Screen Brightness 275 Nit
LCD back light type CCFL
Auto Dimming No
Trigger wire Yes
NTSC/PAL NTSC and PAL
Slide track on back Yes
Image Flip Function No
Built in Speakers No
Stand Mount included Yes, Pedistal stand
Auto on/off Yes
Cigarette Lighter Cord Included No
Audio Video inputs 2 Video Inputs
Wireless Remote Control Yes
Monitor Type Stand alone monitor
Mirror Mount Type No
Back up camera type License Plate Camera
Options No
Product Options No
Homelink No
Built in Bluetooth No Bluetooth
Reverse Image Yes - Reverse Image
Camera Sensor type CMOS
Camera diameter No
Viewing Angle 170 degrees
Parking grid lines Yes
Built in Microphone No
Infrared Illumination Yes
Waterproof ingress protection IP66 - Dust; String Water Jets/Waves
Battery Powered No
Case included No
Connector Type RCA Cable
Wireless Transmission No, wired connection
Color Black
Operation Voltage 12 - 15 volt
Warranty 1 Year
Vehicle Year No
Vehicle Brand No
Vehicle Model No
UPC Code 068888879248

Customer Reviews

Needs better instructions
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
The components seem to be good quality, they supplied enough wire- this was good. Wiring instructions were almost nonexistent . We had lots of wires but no instructions . This made the install very time consuming. (Posted on 6/23/2015)
OK for price
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
Would have been nice if it had come with directions. Had to call tech-suppoprt twice to get it figured out. They were very nice and walked me thru the proper installation. Take notes from them. Could not have got it hooked up without them. RCA cord is long enough for a car but if you are going to install this on an extended cab or crew cab pick-up, you will need to go to your local radio store and buy a longer RCA cable from the camera to the monitor depending on how you route the wire. The cable is 23 feet long and is not quite long enough the way I routed the cable. (Posted on 1/7/2013)
Excellent product,would buy agian!
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
Very good as long as you keep the camera from water (Posted on 4/17/2011)
Picture is pretty lame
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
The instructions arent very detailed. Thankfully I had a very talented individual here who was able to hook it up with minimal directions. (Posted on 12/28/2010)
Nice design
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
Simple easy system, does everything I need it to do. Simple hook up, ease to use. (Posted on 10/14/2010)

Write Your Own Review

You're reviewing: DISCONTINUED - Quality Mobile Video License Plate Back Up Camera System with 5.8" Monitor ZH58P3-SC0301

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Value
Quality
Durability
Install (5 star for easy)
Price

Ask questions receive answers.

Posted by Dale, Friday, October 11, 2013

Question:

can this unit be taped on dash

Answers:

  • Posted by Salvador Diaz on Friday, October 11, 2013
    A:

    Yes, the monitor will have a base included which can be sticked to the dash using double sided tape.

Posted by Bob, Wednesday, June 26, 2013

Question:

In reference to the Quality Mobile Video License Plate Back Up Camera System with 5.8" Monitor ZH58P3-SC0301, Does the Rear View Camera have night vision capabilities? It mentions low light but what about total darkness. Also how long is the provided wiring?

Answers:

  • Posted by Store Owner on Wednesday, June 26, 2013
    A:

    This item does have nightvision capabilities, therefore it will have no problems in complete darkness. The item includes an 18 foot rca cable. The pigtail on the camera is roughly 25 inches long. The cable on the monitor is roughly 5 feet long.

Posted by Ken, Thursday, June 13, 2013

Question:

will this liscense plate camera work on a 2012 chv Captiva that has a push button taile gate release or will the camera interfer with that?

Answers:

  • Posted by Salvador Diaz on Thursday, June 13, 2013
    A:

    You should be fine, if you have enough space for a license plate cover you will have enough space for a license plate camera.

Please login to ask a product question

Item sku:ZH58P3-SC0301
Safesight

Original Price: $109.99

Sale Price: $104.49

Ships Free!
    Quantity Discounts
  • Buy 5 for $101.99 each and save 3%
  • Buy 10 for $96.99 each and save 8%
  • Buy 20 for $92.99 each and save 12%
