System Includes: 4-ch. Class-A/B Amp, Four 5.25" Speakers, Amp Mounting Bracket, Power Harness, Input Harness, Output Harness, Screws, Zip Ties, Velcro Pad, Batwing Grille Badge
Rockford Fosgate R1-HD4-9813 Prime 160 Watt 4-Channel Motorcycle System:
- 4-channel 160 Watt speaker system
- Fits 1998-2013 Harley-Davidson™ factory 4-speaker systems
- Optimized EQ, crossover and gain
- Three position output level control
- Pass-Thru output for future system expansion
- Extruded aluminium heat sink
- Short circuit protection
- Thermal protection
- Multiple mounting options
- Includes all harnesses and hardware for full installation
Power Handling Max:
Power Handling RMS:
- RMS Power: 40 Watts × 4 @ 2-Ohm
- Signal Input: High Level: 4-pin harness
- Signal Output: Pass -Thru: 4-pin harness
- Power Input connector: 3-pin harness
- Output Level Control: Selectable -3dB, 0db, +3dB
- Frequency Response: 80Hz - 16 kHz +/-1dB
- Nominal Impedance: 2-Ohms
- Heat Sink Type: Extruded Aluminium
- Circuit topology Class: Class A/B
- Operating Voltage: 9-16 VDC
- Average Current Draw: 7.5A
- Sensitivity: 88dB
- Speaker Diameter: 5.25" (133 mm)
- Speaker Depth: 2.10” (53.3 mm)
