DISCONTINUED - Sony WX-GS920BH Double DIN Car Stereo Receiver with HD Radio, NFC, Bluetooth and SiriusXM Ready - 100 Watts x 4 High power amp

$278.99
Out of stock
SKU
WX-GS920BH

Key Features

This item has been discontinued.
Click here for new model.

Unit includes: Single DIN Stereo, Remote control, Wiring harness, Mounting hardware, Bluetooth microphone and Instruction manual


Sony WX-GS920BH Double DIN Car Stereo Receiver with HD Radio, NFC, Bluetooth and SiriusXM Ready - 100 Watts x 4 High power amp
    Features:
  • Double DIN In-Dash CD receiver
  • Amazing high power 4-channel amplifier with Output: 4 channels x 100 watts Peak and 4 channels x 45 watts RMS (CEA rated)
  • Internal amplifer is as capable as a seperate amp and can be bridged for single subwoofer output
  • Subwoofer Direct Connect - with this feature you can bridge the rear channels to generate 60 watts RMS to power a subwoofer without an external amplifier!
  • Full detachable face with dual-zone variable color illumination
  • Multi-Segmented 13 Digital 2 Line LCD Display
  • Variable color button illumination with 2 zone illumination to match your factory button color
  • Button Illumination has Sound and color synchronization for DJ like effects
  • Dimmer and brightness control
  • Built in Bluetooth for phone calls and wireless audio streaming
  • Voice control from Android or iOS smartphones via Bluetooth connection
  • Siri Eyes Free voice control for iphone
  • Voice control for Android
  • Pandora Internet radio control via Bluetooth
  • Carbon Fiber faceplate for extra clean look
  • Displays CD text and MP3 ID3 Tag including title, artist & album
  • Steering wheel control input
  • Front and rear USB input for thumb-drives


Media playback features:
  • Plays CD-RW, CD-R, FLAC, AAC, WAV, MP3 and WMA
  • Electronic shock protection with built in buffer
  • MP3/WMA/AAC/FLAC/WMA Audio Playback on USB
  • MP3 ID3 tag information, display artist and song information
  • FLAC Audio Playback for high definition audio downloads (Up to 48kHz/16bit)
  • Sony Music Center App Compatible
  • 24-bit Digital to Analog Converter
  • AOA 2.0-compatible USB


Audio features:
  • 10-band parametric equalizer with 8 preset and custom options (R and B / Karaoke / Rock / Pop / Hip-Hop / EDM / Jazz / Soul / Country / Custom)
  • Clear Audio + Reproduces sound by optimizing the digital signal
  • DSO: Dynamic Stage Organizer adjusts the signal, improving the stereo positioning so music sounds like it's coming from right in front of you
  • DSEE: Improves digitally compressed sound by restoring high frequencies lost in the compression process
  • Intelligent Extrabass: Level1 / Level2 / Off
  • Manual EQ with 32 Hz / 63 Hz / 125 Hz / 250 Hz / 500 Hz / 1 kHz / 2 kHz / 4 kHz / 8 kHz / 16 kHz ±6dB
  • High-Pass filter with variable slopes and crossover frequencies (Adjustable: 50 Hz / 60 Hz / 80 Hz / 100 Hz / 120 Hz) and (Adjustable slopes from -6dB / -12dB / -18dB)
  • Variable subwoofer level control (-10dB to +10dB) with selectable Low-Pass digital crossover filter (Adjustable from 50 Hz / 60 Hz / 80 Hz / 100 Hz / 120 Hz) with variable slopes (Adjustable from -6dB / -12dB / -18dB)
  • Subwoofer phase control 0° - 180°
  • Sound Synchronization displays color changes timed to your music
  • Digital time alignment with independent front, rear, and subwoofer delay
  • 3-mode Rear Bass Enhancer, enhances the bass sound by applying a low pass filter setting to the rear speakers
  • Subwoofer direct connection - You can use the subwoofer without a power amplifier when it is connected to the rear speaker lead.


Tuner features:
  • Includes HD Radio AM & FM tuner with 30 preset stations memory
  • RDSB (Radio data service) Tuner
  • SiriusXM radio ready with SXV300 Sirius XM tuner
  • SiriusXM radio replay, replay up to the last 60 minutes of your current channel
  • SiriusXM radio SmartFavorites - automatically buffers the broadcast audio content of SmartFavorites channels in the background so you can rewind or replay any missed content


    Bluetooth features:
  • Integral Bluetooth technology facilitates convenient hands-free phone calls and audio streaming
  • NFC: Near Field Communication auto pairing
  • A2DP 1.3: Advanced Audio Distribution Profile allows high quality audio to be streamed from an audio device to the car stereo
  • AVRCP 1.5: Audio/Video Remote Control Profile supports basic remote control functions (play, pause, etc) via Bluetooth
  • SPP: Serial Port Profile provides a wireless replacement for RS-232 based serial communications
  • HFP 1.5: Hands Free Profile allows a hands-free car kit to connect to a compatible mobile phone
  • PBAP: Phone Book Access Profile allows the car stereo to display the name of the incoming caller, as well as access the contact list
  • External microphone with 10 foot cord for optimal placement
  • Bluetooth 3.0 certified
  • Siri Eyes Free voice support
  • Voice control for Android
  • NFC for easy pairing of Bluetooth devices
  • Full voice recognition with SMS text response
  • Supports dual simultaneous phone connections


Inputs and outputs:
  • 3 - 5V preamp outputs (Front, Rear and Subwoofer) Preout Impedance : 220 ohms
  • 1 - 3.5 mm front audio input for connection to external source
  • 1 - SiriusXM radio tuner input
  • 1 - Front USB connection with High power charging
  • 1 - Rear USB connection
  • 1 - Rear microphone input
  • 1 - Steering wheel control input requires ASWC steering wheel interface


    Dimensions:
  • Single DIN chassis
  • Dimensions: 7"W x 7-1/8"D x 2"H
More Information
Manufacturer Sony
Part Number WX-GS920BH
Chassis Size Double DIN
Illumination color Full Color
Faceplate features None
Disc Playback CD
Anti-Shock Yes
Built in Bluetooth Built in Bluetooth
NFC (Near Field Communication) No
HD Radio Yes
Radio Data Service - RDS Yes
Satellite Radio Sirius XM Ready
Front mounted auxiliary input 3.5 mm audio input
Audio Video inputs 1 Audio Input
USB input Dual USB
SD Card input No
Audio Formats AAC, FLAC, Mpeg-3, WAV, WMA
RCA Pre-amp Audio outputs 3 Pairs (Front, Rear, Sub)
Preamp voltage 5 volts
Steering Wheel Control Yes, requires external module
Built in Crossover High-pass, Low-pass
Wireless Remote Control Yes
Warranty 1 Year
Return period 30 days
Exchange period 30 days
