PAC AOEM-CHR3 2007 and Up Chrysler / Dodge / Jeep add an amplifier interface
$50.99
In stock
SKU
AOEM-CHR3
- Fits 2007 and Up select Chrysler / Dodge / Jeep vehicles
- Interface is designed to be used with factory radios and converts radio outputs to aftermarket amplifier audio connections
- Provides front and rear low level outputs
- Provides full range audio output 20-20,000Hz
Unit includes: A) AOEM-CHR3 interface, B) PAC RCA harness, C) Chrysler / Dodge / Jeep harness, and Instruction manual
PAC AOEM-CHR3 2007 and Up Chrysler / Dodge / Jeep amplified audio system interface:
Interface Features:
PAC AOEM-CHR3 2007 and Up Chrysler / Dodge / Jeep amplified audio system interface:
Interface Features:
- Provides line level output for aftermarket amplifiers and makes adding or replacing an amplifier easy
- Works with non-amplified, audio systems
- Not compatible with premium amplified systems
- If the vehicle has a factory amplifier it must be removed
- Not compatible with Navigation equipped vehicles
- Interface is designed to be used with factory systems and converts factory radio outputs to and aftermarket amplifier
- 4 - High level speaker inputs makes connections for aftermarket amplifier easy
- Provides front and rear low level outputs
- Retains balance and fader
- Provides full range audio output 20-20,000Hz
- Interface is transformer isolated to prevent damage to factory radio in the event of an issue with aftermarket amplifier
-
Connections:
- Black - Ground
- Red - 12 volts (+)
- Yellow - 12 volts Accessory (+)
- Green - Left Rear Speaker (+)
- Green with Black Stripe Left Rear Speaker (-)
- White - Left Front Speaker (+)
- White with Black Stripe - Left Front Speaker (-)
- Purple - Right Rear Speaker (+)
- Purple with Black Stripe - Right Rear Speaker (-)
- Gray - Right Front Speaker (+)
- Gray with Black Stripe - Right Front Speaker (-)
-
Kit Components:
- A) AOEM-CHR3 interface
- B) RCA harness
- C) 22-pin harness to 22-pin Chrysler / Dodge / Jeep harness
- D) Instruction manual
-
Tools Required:
- Panel Removal tool
- Cutting tool
- Crimping tool
- Electrical tape
- Crimp connectors
-
Vehicle Applications:
-
Chrysler
- 2008 300
- 2007 - 2008 Sebring
- 2008 - 2012 Town and Country
-
Dodge:
- 2008 Avenger
- 2008 Charger
- 2008 Dakota
- 2008 Durango
- 2009 - 2010 Grand Caravan
- 2009 Journey
- 2007 - 2010 Nitro
- 2009 - 2010 RAM
-
Jeep:
- 2008 Commander
- 2008 Grand Cherokee
- 2008 - 2010 Liberty
- 2007 - 2010 Wrangler
- 2007 - 2010 Wrangler Unlimited
Manufacturer | PAC |
---|---|
Part Number | AOEM-CHR3 |
Wiring harness function | Replace Factory Radio |
Warranty | 1 Year |
Vehicle Brand | Chrysler, Dodge, Jeep |
UPC Code | 606523107556 |
Return period | 30 days |
Exchange period | 30 days |
