Kenwood KAC-7005PS 5-Channel Power Amplifier
Expert Knowledge
Talk to a specialist
- 5-Channel Power Amplifier
- 5 / 3 channel operation
- Pulse Width Modulated MOSFET power supply
- 5 Channel preamp RCA inputs
- 3-way protection circuitry (thermal, overload, and speaker short protection)
- LED power (green) and protect (red) indicators
- CEA-2006 Compliant
Kenwood KAC-7005PS Class-AB 5 Channel Power Amplifier
- Features
- Class AB amplifier for excellent fidelity and sound quality
- Can operate as a 5 / 3 Channel operation for ultimate system flexibility
- Power MOS-FET Switching Power Supply
- Terminal Cover to disguise inputs and outputs and all adjustments
- 2 Ohms Load Capability in Stereo mode
- Cast Aluminum Heat Sink Design
- Built in Variable High-Pass Filter Channels 1 - 2 - 3 - 4 (50 Hz - 200 Hz, -12dB/oct)
- Built in Variable Low-Pass Filter Channels 5 (50 Hz - 200 Hz, -24dB/oct)
- Built in Bass Boost Channels 5 (40 Hz, 0dB - 18dB)
- Frequency Response: 5Hz - 50kHz (+0dB, -3dB)
- Signal to Noise Ratio: 100dB (Reference: Rated Power into 4Ohms at 14.4V)
- Input Impedance: 10k ohm
- Speaker Impedance: 4Ω (2Ω to 8Ω allowable), Bridged connection 4Ω to 8Ω Allowable
- CEA-2006 Compliant
- Max Power Output
- 700 Watts
- RMS Power Output
- 4 Ohms: 40 Watts x 4 + 300 Watts x 1
- 2 Ohms: 50 Watts x 4 + 500 Watts x 1
- Bridged at 4 Ohms: 100 Watts x 2 + 300 Watts x 1
- Inputs and Outputs
- Battery & Ground: Screw Type Terminal Block (Ni) (M6)
- Speaker Output: Screw Type Terminal Block (Ni) (M4)
- Line-in: RCA (Ni)
- Speaker Level Input: JST Connector
- Dimensions
- 335mm x 56mm x 192mm
- 13-3/16" (W) x 2-3/16" (D) x 7-9/16" (H)
| Manufacturer | Kenwood |
|---|---|
| Part Number | KAC-7005PS |
| Amplifier Topology Class | Class AB |
| Number of Channels | 5 Channel |
| Amplifier Bridging | Bridgable @ 4 ohms |
| Minimum Impedance in Bridged Mode | 4 ohm |
| Minimum Impedance in Un-Bridged Mode | 2 ohm |
| Strappable Amplifier | No |
| RCA Pre-amp Audio outputs | 3 Pairs (Front, Rear, Sub) |
| Preamp voltage | 5 volts |
| Speaker level inputs | No |
| Gain Control | Yes |
| Bass Knob / Remote Gain | No |
| Built in Crossover | High-pass, Low-pass |
| Cooling Fan | No |
| Color | Black |
| Warranty | 1 Year |
| CEA2006 Compliant | No |
| UPC Code | 019048197597 |
| Return period | 30 days |
| Exchange period | 30 days |
