Voyager VCAHD104RCM 1/3" Right Side Mount Color Camera with 150 degree Wide Angle - Primed to Paint housing
$249.99
In stock
SKU
VCAHD104RCM
Expert Knowledge
Talk to a specialist
- Designed for Voyager camera systems
- Right Side mount camera
- 1/3" CMOS Image Sensor
- 700 TV lines of resolution
- Rugged two piece housing for added durability and ability to paint housing
- 4-Pin connector
Unit includes: Side Camera, Camera housing, Mounting hardware, Camera cover, and Instruction manual
Left Side Mount camera
Voyager VCAHD104RCM 1/3" Right Side Mount Color Camera with 80 degree Wide Angle - Primed to Paint housing
Left Side Mount camera
The Voyager VCAHD104RCM side mount camera is a high quality CMOS camera that is designed for side mount applications. The VCMS50RCM is a two piece camera with a aluminum metal cosmetic housing that is primed and ready to paint to match any RV or commercial vehicle. The high performance 1/3 inch CMOS sensor has excellent picture quality during the day and has spectacular image quality at night. The right side camera has regular image so that what you see on screen is exactly what is taking place beside you. Stay safe and see everything that is taking place all around you with a complete Voyager camera system.
Voyager VCAHD104RCM 1/3" Right Side Mount Color Camera with 80 degree Wide Angle - Primed to Paint housing
-
Models:
- VCAHD140LWT: Primer Left Side Mount camera
- VCAHD140RWT: Primer Right Side Mount camera
-
Features:
- Camera is compatible with AHD Voyager Back Up Camera Systems
- Ideal for Heavy Duty and Commercial Vehicles (Truck, RV, Bus, Van, Tractor, Trailer, Crane, Dirt Wagon, etc)
- Designed as a Right Side mount camera
-
Features:
- High Resolution Side Mount Camera
- 1/3" CMOS Image Sensor
- 700 TV lines of resolution
- 150° diagonal, 115° horizontal, 90° vertical angle of view
- Regular image
- Camera is fixed within housing and has rubber base plate for better vibration damping
- 0 LUX (With IR on) for great low light situations
- IP69K rated for Waterproof, Shockproof and High Temperature Resistance
- Right Side Mount Application
- High strength aluminum cosmetic housing that prevents permanent damage to the camera
- 4 Pin Waterproof Voyager Connector
- Dimensions: 3-1/4" (L) x 1-3/4" (H) x 1-3/4" (D)
| Manufacturer | Voyager |
|---|---|
| Part Number | VCAHD104RCM |
| Camera Sensor type | CMOS |
| Back up camera type | Right - Side Mount Camera |
| Camera diameter | 1/3" |
| Viewing Angle | 120 degrees |
| Wireless Transmission | Wired connection |
| Waterproof ingress protection | IP69K - Dust; High Pressure and Temperature rating |
| Reverse Image | No - Normal Image |
| Parking grid lines | No |
| Infrared Illumination | Yes |
| Built in Microphone | No |
| Connector Type | 4 Pin Connector |
| Modulation | AHD |
| Operation Voltage | 12-24 Volt DC |
| Battery Powered | Hard wired |
| Overall Height | 1.33 inches |
| Overall Length | 2.75 inches |
| Overall Width | 1.75 inches |
| Warranty | 1 Year |
| Return period | 30 days |
| Exchange period | 30 days |
