DISCONTINUED - Back Up System Combo Kit - Boyo (Vision Tech) VTM3600 3.6 inch LCD Back Up Monitor and Boyo VTL110 Chrome or VTL120 Black License Plate Camera

Rating:
80% of 100
Out of stock
SKU
47488

Key Features

  • 3.6" LCD Monitor
  • Dual Video Input for Additional Camera or Video Source
  • 2 Colors to Choose From
  • Easy Mounting License Plate Camera
Unit includes: Pedesal Stand

Boyo (Vision Tech) VTM3600 3.6 inch Digital Panel LCD Back Up Monitor
  • 3.6 inch TFT LCD monitor
  • Reverse trigger input
  • 2 Video input
  • Pedestal mount
  • Display Pixel: 480 x 240
  • Display Format: 4:3 Aspect ratio
  • Color: RGB
  • Video System: NTSC
  • Input Voltage: DC12 - 16V
  • Input Signal: Composite video signal
  • Operating Temperature: -20 degrees C to 60 degrees C

Unit includes: Mounting Accessories

Boyo VTL110 Plastic Chrome and VTL120 Plastic Black License Plate Camera
  • VTL110 = License Plate Camera "Plastic in Chrome"
  • VTL120 = License Plate Camera "Plastic in Black"

  • High sensitive 1/3" DSP Color CCD built-in
  • 380 TVL Horizontal Resolution
  • Remarkable True Color reproduction
  • Remarkable low Lux performance of 0.3 Lux at F2.0
  • Excellent Auto White Balance
  • Waterproof(IP67) Reverse Image
  • Imager: 1/3" DSP Color CCD, (High sensitive)
  • Effective Pixels NTSC : 512(H)X492(V)
  • Horizontal resolution: 380 TV Lines
  • Total number of pixels: NTSC: 270K
  • Minimum Illumination: 0.3 Lux at F2.0
  • Synchronizing system: Internal
  • Scanning system: 2:1 Interlaced
  • Video output: 1Vp-p 75 ohm composite
  • S/N Ratio: More than 48dB
  • Electronic iris: 1/50,1/60-1/100,000 sec.
  • Smear effect: 0.005%
  • Gamma correction: r = 0.45
  • White balance: Auto.2100'K - 9100'K
  • Gain control: Auto. 4dB - 30dB
  • Lens mount: 2.8mm Pinhole lens (130 degrees D)
  • MTBF: 80,000 hours
  • Power source: DC12V(Tolerance: 6V-35V)
  • Operating current: 90mA w/regulated power in
  • Operating Temp: -4 degrees F~122 degrees F ( -20 degrees C~ + 50 degrees C )
  • Storage Temp: -40 degrees F~176 degrees F ( -40 degrees C~ + 80 degrees C )
  • Humidity: Within 90% RH
  • Measurement: Camera Size: 108X22 (Camera)
  • Weight(Approx.g): 400g

  • Product Manual

More Information
Manufacturer Boyo
Part Number VTM3600-VTL110-VTL120
Camera Sensor type CCD
Back up camera type License Plate Camera
Waterproof ingress protection IP67 - Dust; Immersion up to 1 m
Reverse Image Yes - Reverse Image
Modulation NTSC only
Warranty 1 Year
Return period 30 days
Exchange period 30 days
