DISCONTINUED - Pioneer FH-X520UI Double-DIN In-Dash CD Receiver with USB control for iPod and iPhone and Pandora
Expert Knowledge
Talk to a specialist
- Double-DIN in-dash CD receiver
- Custom color illumination
- Built-In MOSFET 50W x 4 Amplifier
- iPhone Pandora support
- 2 sets of 2 volt RCA outputs
- Front USB connection
- Front 3.5mm Audio connection
Pioneer FH-X520UI Double-DIN In-Dash CD Receiver
- Features:
- Double DIN In-Dash CD receiver
- Multi-Segmented 2-Line LCD Display with LED Backlight
- Full color custom illumination with dual zone color control and up to 210,000 possible colors
- AM/FM radio tuner
- iPod and iPhone control with standard USB to lightning interface cable, simply connect your iPhone or iPod touch and access your entire music library
- Pandora support for iPhone with CD-IU52 interface cable, simply connect your iPhone and stream Pandora
- Android music support through MTP
- Power Output: 4 channels x 50 watts peak and 4 channels x 22 watts RMS
- MP3, WAV & WMA playback from CD's and USB
- Displays CD text and MP3 ID3 Tag including title, artist & album
- Easily accessible with wireless remote and graphic touch screen
- Enjoy Your Favorite Music in a Non-Stop Mix with MIXTRAX
- Advanced Sound Retriever
- Audio features:
- Plays CD, CD-R, CD-RW, MP3, ACC, WAC and WMA
- Electronic shock protection with built in buffer
- Includes Supertuner IIID AM & FM tuner with 18 FM station 6 AM presets memory
- Controls: Volume, Fader, Bass, Treble, Balance
- 5-band Graphic equalizer with 6 preset and 1 custom options
- Variable subwoofer level control with selectable Low-Pass digital crossover filter 50Hz, 63Hz, 80Hz, 100Hz, 125Hz, 160Hz, 200Hz with 6db or 12db slopes
- Bass Boost
- Normal and Reverse subwoofer phase control
- CD text information, display artist and song information
- MP3 ID3 tag information, display artist and song information
- 3 Loudness modes
- Tuner features:
- Includes AM & FM tuner with 24 preset stations memory
- Best Station Memory (BSM)
- Inputs and outputs:
- 2 Sets of 2V preamp outputs (front, rear)
- 1 - Front USB connection accepts up to a 32Gb
- 1 - Front 3.5mm Audio connection for connection to multiple devices
- 1 - Rear Steering wheel interface control input
- Dimensions:
- Double DIN chassis
- Dimensions: 7"W x 7-1/4"D x 4"H
| Manufacturer | Pioneer |
|---|---|
| Part Number | FH-X520UI |
| Chassis Size | Double DIN |
| Illumination color | Full Color |
| Faceplate features | None |
| Disc Playback | CD |
| Anti-Shock | Yes |
| Built in Bluetooth | No Bluetooth |
| NFC (Near Field Communication) | No |
| HD Radio | No |
| Radio Data Service - RDS | Yes |
| Satellite Radio | No |
| Front mounted auxiliary input | 3.5 mm audio input |
| USB input | Yes |
| SD Card input | No |
| Audio Formats | Mpeg-3, WAV, WMA |
| RCA Pre-amp Audio outputs | 2 Pairs (Front, Rear) |
| Preamp voltage | 2 volts |
| Steering Wheel Control | Yes, requires external module |
| Built in Crossover | High-pass, Low-pass |
| Wireless Remote Control | Yes |
| Warranty | 1 Year |
| UPC Code | 884938256636 |
| Return period | 30 days |
| Exchange period | 30 days |
Car stereo installation
We show you the complete process of installing a Pioneer Double DIN car stereo in a Chevy truck. The in-depth video shows the installation of the interface, and steering wheel control.
Stereo Installation Basics
Let's start with the basics of replacing your car stereo receiver. In out first video we demonstrate how to crimp or solder your wiring, mount your new receiver to your dash kit and prepare everything for an installation in your vehicle.
Wiring Harnesses Explained
What do all of the wire colors mean? Aftermarket manufacturers have made car stereo receiver installation an easier process by using a standardized wire color scheme. We walk you through what each individual wire does, this way if you have an installation that doesn't perform properly you will have the resources to begin troubleshooting your installation.
Simple radio Installation
In our third video we demonstrate this installation process from start to finish. We show you the complete process of installing a Pioneer Double DIN car stereo in a Chevy truck. The in-depth video shows the installation of the interface, and steering wheel control.
Complex radio Installation
In our fourth video we demonstrate a much more difficult installation of a Car Stereo receiver. In this video we are using a more complicated dash kit and a difficult level of installation.
