PAC AOEM-GM1416 2006 and Up Select General Motors add an amplifier interface

$57.99
In stock
SKU
AOEMGM1416

Key Features

  • Fits 2006 and up select General Motors vehicles
  • Interface is designed to be used with factory radios and converts radio outputs to aftermarket amplifier audio connections
  • Provides front and rear low level outputs
  • Provides full range audio output 20-20,000Hz
Unit includes: A) AOEM-GM1416 interface, B) 16-pin harness, C) 14-pin harness to 10-pin and 28-pin General Motors harness, and Instruction manual

PAC AOEM-GM1416 2006 and Up General Motors amplified audio system interface:
    Interface Features:
  • Provides line level output for databus vehicles and makes adding an amplifier easy
  • Works with non-amplified, audio systems
  • Not compatible with premium factory amplified systems
  • Not compatible with Navigation equipped vehicles
  • Interface is designed to be used with factory systems and converts factory radio outputs to and aftermarket amplifier
  • 4 - High level speaker inputs makes connections for aftermarket amplifier easy
  • Provides front and rear low level outputs
  • Retains balance and fader
  • Provides full range audio output 20-20,000Hz
  • Interface is transformer isolated to prevent damage to factory radio in the event of an issue with aftermarket amplifier
    Connections:
  • Green – Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White – Left Front Speaker (+)
  • White with Black Stripe – Left Front Speaker (-)
  • Purple – Right Rear Speaker (+)
  • Purple with Black Stripe – Right Rear Speaker (-)
  • Gray – Right Front Speaker (+)
  • Gray with Black Stripe – Right Front Speaker (-)
    Kit Components:
  • A) AOEM-GM1416 interface
  • B) 16-pin harness
  • C) 14-pin harness to 10-pin and 28-pin General Motors harness
  • D) Instruction manual
    Vehicle Applications:
    Buick:
  • 2008 - 2011 Enclave
  • 2006 - 2011 Lucerne
    Cadillac:
  • 2006 - 2011 DTS
  • 2012 - 2013 Escalade
  • 2007 - 2009 SRX
    Chevrolet:
  • 2007 - 2013 Avalanche
  • 2007 - 2008 Equinox
  • 2006 - 2013 Impala
  • 2006 - 2007 Monte Carlo
  • 2007 - 2013 Silverado
  • 2007 - 2013 Suburban
  • 2007 - 2013 Tahoe
  • 2009 - 2012 Traverse
    GMC:
  • 2007 - 2013 Acadia
  • 2003 Savana
  • 2007 - 2013 Sierra
  • 2007 - 2013 Sierra HD
  • 2007 - 2013 Yukon
  • 2007 - 2013 Yukon XL
    Hummer:
  • 2008 - 2009 H2
    Pontiac:
  • 2007 - 2009 Torrent
    Saturn:
  • 2007 - 2009 Outlook
  • 2008 - 2009 Vue
    Suzuki:
  • 2007 - XL-7
More Information
Manufacturer PAC
Part Number AOEM-GM1416
Wiring harness function Replace Factory Radio
Warranty 1 Year
Vehicle Brand Buick, Cadillac, Chevrolet, GM, GMC, Hummer, Pontiac, Saturn, Suzuki
Return period 30 days
Exchange period 30 days
