Audiovox CAM500 Universal Tailgate Handle Back Up Camera

Audiovox CAM500 Universal Tailgate Handle Back Up Camera

Audiovox CAM500 Universal tailgate handle back up camera - Main

More Views

Audiovox
Free Shipping on orders $99+

Overall Rating 3.4 (Based on 2 reviews)

Audiovox CAM500 Product Highlights

  • Universal Tailgate Camera for down-looking view
  • 170° extended view
  • Selectable parking lines and reverse/non-reverse image
  • CMOS image sensor for excellent detail in normal and low light
Expert Advice is a phone call away

Expert Knowledge

Talk to a specialist

Frequently Bought Together

Overview

Unit includes: Back up camera, Mounting tab, 20 foot RCA cable, DC power cable and Instruction manual

Audiovox CAM500 surface mount reverse image back up camera
    Features:
  • Universal surface and partial flush mount back up camera designed to be mounted underneath a ledge or overhang
  • Designed to be drilled in and held in place with a retainer nut
  • Aluminum powder coated housing
  • CMOS image sensor for excellent detail in normal and low light
  • 170° extended view for full behind vehicle safety
  • Waterproof under vehicle connection with disconnect protection
  • Selectable parking lines and reversible viewing angle
  • 3 Year Warranty
    Specifications:
  • Resolution: 720 x 480
  • Minimum Illumination: < 0.3 Lux

Technical Specifications

Manufacturer Audiovox
Part Number CAM500
Auto Dimming No
Camera Sensor type CMOS
Back up camera type Top down Camera
License Plate Camera Type No
Camera diameter 2.96 mm
Viewing Angle 170 degrees
Wireless Transmission No, wired connection
Waterproof ingress protection IP67 - Dust; Immersion up to 1 m
Reverse Image Yes - Reverse Image
Parking grid lines Yes
Infrared Illumination No
Built in Microphone No
Trigger wire Yes
Auto on/off Yes
Connector Type RCA Cable
NTSC/PAL NTSC only
Operation Voltage 12 - 15 Volt DC
Battery Powered Hard wired
Cigarette Lighter Cord Included No
Color Black
Case included No
Built in Speakers No
Overall Height 0 Inches
Overall Length 0 Inches
Overall Width 0 Inches
Warranty 1 Year
UPC Code 044476113116

Customer Reviews

Lasted 14 months
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
After 14 months the image was fuzzed out and unusable. This was mounted on the vertical surface of my canopy door. (Posted on 9/2/2016)
Good Product
Review by
Value
Price
Install (5 star for easy)
Durability
Quality
Camera works well and shipped as scheduled. (Posted on 1/22/2016)

Write Your Own Review

You're reviewing: Audiovox CAM500 Universal Tailgate Handle Back Up Camera

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Value
Quality
Durability
Install (5 star for easy)
Price

Ask questions receive answers.

Posted by Alton H Wagnon, Wednesday, March 14, 2018

Question:

I want to verify that the Audiovox CAM500 Universal Tailgate Back Up Camera can be mounted on a vertical surface. I bought an Audiovox ACA501 camera from another company that said it could be mounted on a vertical surface, but the image was upside down. Turns out it had to be mounted under a lip on the trunk of a car with a horizontal surface. I'm wanting to mount this on the face of the tailgate handle of a Tundra pickup or on the flat vertical metal just below the handle. Thank you in advance.

Answers:

  • Posted by Store Owner on Monday, March 19, 2018
    A: Yes, this can be mounted in the orientation, it does both. It does have a reverse/non-reverse wire that you can use to properly orientate the camera once it is installed.
