Wireless or wired Pandora Control for iPhone and Android
Wireless or wired Spotify Control for iPhone and Android
Hi-Res audio compatible for excellent sound quality from higher quality audio files
Media playback features:
Plays CD-RW, CD-R, MP3, AAC, WAV, FLAC, and WMA
Region 1 DVD player
Electronic shock protection with built in buffer
MP3/WMA/WAV/WMV/AAC/FLAC Playback on CD/USB
Displays text, tags and titles for artist and album
Linear PCM 96kHz/24-Bit/32-bit decoder for excellent digital audio quality
Audio features:
13-band parametric equalizer with 8 preset and custom options (Drive EQ / Flat / Rock / Pops / Easy / Powerful / Top 40 / Jazz) and (Adjustable from ±9dB)
High-Pass filter with variable slopes and crossover frequencies (Adjustable from 50 to 220 Hz) and (Adjustable slope from -6dB / -12dB / -18dB / -24dB)
Low-Pass filter with variable slopes and crossover frequencies (Adjustable from 50 to 120 Hz) and (Adjustable slope from -6dB / -12dB / -18dB / -24dB)
Variable subwoofer level control (-50dB to +10dB) with selectable low-Pass digital crossover filter (Adjustable from 50 to 120 Hz) with variable slopes (Adjustable slope from -6dB / -12dB / -18dB / -24dB)
Speaker size setup for perfect crossover mapping from subwoofer to door speakers (Standard, Narrow, Middle or Wide speaker type)
Loudness function (Boost bass and upper frequencies)
Drive EQ boosts specific frequencies in the audio signal to compensate the negative impact of road noise
Digital time alignment with independent front, rear, and subwoofer delay
High-resolution audio playback 96kHz/24-Bit audio with K2 audio technology
Subwoofer Level
Tuner features:
HD AM & FM radio tuner with 20 preset stations memory
We show you the complete process of installing a Pioneer Double DIN car stereo in a Chevy truck. The in-depth video shows the installation of the interface, and steering wheel control.
Stereo Installation Basics
Let's start with the basics of replacing your car stereo receiver. In out first video we demonstrate how to crimp or solder your wiring, mount your new receiver to your dash kit and prepare everything for an installation in your vehicle.
Wiring Harnesses Explained
What do all of the wire colors mean? Aftermarket manufacturers have made car stereo receiver installation an easier process by using a standardized wire color scheme. We walk you through what each individual wire does, this way if you have an installation that doesn't perform properly you will have the resources to begin troubleshooting your installation.
Simple radio Installation
In our third video we demonstrate this installation process from start to finish. We show you the complete process of installing a Pioneer Double DIN car stereo in a Chevy truck. The in-depth video shows the installation of the interface, and steering wheel control.
Complex radio Installation
In our fourth video we demonstrate a much more difficult installation of a Car Stereo receiver. In this video we are using a more complicated dash kit and a difficult level of installation.
