AudioControl LC7i Six Channel Line Out Converter with AccuBASS
$203.99
In stock
SKU
LC7i
Expert Knowledge
Talk to a specialist
- Six channels of active speaker level inputs - accepts up to 400 watts per channel
- Designed for maximum sound quality and enhanced audio performance
- Corrects for the bass roll-off that is common with many factory-installed audio systems
- Internal Channel Summing
- Signal sense with remote turn on output
AudioControl LC7i Six Channel Line Out Converter with AccuBASS
- Features:
- Six channels of active speaker level inputs - accepts up to 400 watts per channel
- Designed for maximum sound quality and enhanced audio performance
- Corrects for the bass roll-off that is common with many factory-installed audio systems
- Restores the Bass as the volume is turned up, improving the audio performance
- GTO™ (Great Turn-On) Circuit - Powers up the LC7i when it detects signal on the speaker level input
- Patent Pending AccuBASS™ circuitry
- Optional ACR-1 Remote allows for user control of the subwoofer level
- Internal Channel Summing for interfacing with factory installed amplifiers
- Ideal for use while adding amplifiers to the OEM system of your vehicle
- Built in remote turn-on circuit for factory systems that do not use remote signals
- Three gain controls for matching outputs
- Precision matched stereo
- Full 10Hz to 22kHz frequency response (+/- 1.5 dB)
- Compact size
- Inputs and Outputs:
- (6) - Speaker level inputs
- (6) - RCA outputs
- (1) - 12 volt input
- (1) - Ground input
- (1) - 12 volt remote turn on (Input)
- (1) - 12 volt remote turn on (Output)
- Dimensions:
- Size: 7-1/2" (W) x 4-3/4" (D) x 1-1/4" (H)
- Technical Specifications:
- Maximum speaker-level input: 400 watts @ 4 ohms
- Maximum output level: 8.5Vrms
- Output gain: ±15 dB
- Frequency response: 10Hz - 22,000 Hz
- Total harmonic distortion: 0.01%
- Input Impedance: 20 Kohms
- Output Impedance: 150 ohms
- Power supply: High headroom PWM switching
- Power draw: 350mA
- Recommended fuse rating: 2 Amp
- Remote Trigger Output Current: 1 Amp
| Manufacturer | AudioControl |
|---|---|
| Part Number | LC7i |
| Number of Channels | 6 Channel |
| Remote turn on circuit | Yes |
| Bass Knob / Remote Gain | Optional |
| Bass Correction | Built in bass correction |
| Warranty | 1 Year |
| Return period | 30 days |
| Exchange period | 30 days |
Write Your Own Review
What is a Line Output Converter (LOC)?
A Line Output Converter (LOC) is an essential car audio device that converts high-level speaker outputs from a factory radio or amplifier into low-level RCA signals that aftermarket amplifiers can use.
Why Do You Need a Line Output Converter?
Most factory head units do not have dedicated RCA preamp outputs. A LOC bridges the gap by stepping down high-voltage speaker signals (typically 2–20 volts) into clean low-level signals (0.5V–5V) suitable for amplifiers.
Types of Line Output Converters
| Type | Power Source | Advantages | Disadvantages | Best For |
|---|---|---|---|---|
| Passive LOC | No power needed | Simple, inexpensive, reliable | Lower output, potential bass loss | Basic systems |
| Active LOC | Requires +12V power | Higher output, cleaner signal, adjustable gain | More expensive | High-performance systems |
Key Features
- High-level speaker wire inputs
- Low-level RCA outputs (2 or 4 channels)
- Gain control for output level adjustment
- Ground isolation to reduce noise
- Remote turn-on output with signal sense
- Vehicle-specific T-harnesses (plug & play)
Common Applications
- Adding aftermarket subwoofers and amplifiers
- Upgrading factory speakers with external amplification
- Integrating DSP processors
- Creating hybrid factory + aftermarket audio systems
Pro Tip: For vehicles with multiple amplifiers, an SPDT relay is often recommended for proper remote turn-on functionality.
