Axxess AXDIS-VL32 2012 - and Up Volvo XC90 radio replacement CAN-BUS interface

$179.99
Out of stock
SKU
AXDIS-VL32

Key Features

  • Volvo complete radio replacement interface for plug-and-play installation of an aftermarket car radio
  • Integrated steering wheel control interface for direct plug in to aftermarket radio
  • Provides NAV outputs (parking brake, reverse, and speed sense)
  • Retains the 3.5mm AUX-IN jack
  • Includes 5v factory amplifier step-down
Unit includes: AXTC-FD1 Interface control box, 16 pin wire harness, 18 pin to 12 pin and 24 pin harness, Female 3.5mm connector with stripped leads, and Instruction manual

Axxess AXDIS-VL32 2012 - and Up Volvo XC90 radio replacement CAN-BUS interface
    Features:
  • Easily remove the factory stereo in an otherwise impossible situation and replace it with an aftermarket stereo and retain all of the factory functions
  • Provides accessory (12-volt 10-amp)
  • Retains R.A.P. (retained accessory power)
  • Retains chimes
  • Provides NAV outputs (parking brake, reverse, mute, V.S.S.)
  • Integrated steering wheel control interface for direct plug in to aftermarket radio
  • Retains memory settings even after battery disconnection or interface removal (non volatile memory)
  • Retains the 3.5mm AUX-IN jack
  • Includes 5v factory amplifier step-down
  • High level speaker input
  • USB updatable
  • Axxess AXTC-VW2 2015 - and Up Volkswagen radio replacement interface Instruction manual
    Connections:
  • Yellow - 12V Constant
  • Red - 12V Accessory
  • Black - Ground
  • Orange/White - Dash Light Dimmer/Illumination
  • Blue/White - Amplifier turn on
  • Brown - Mute connection
  • Light green - (-) Parking brake lead
  • Blue/Pink - VSS (Vehicle speed sensor)
  • Black/Yellow - OnStar volume adjustment
  • White RCA - Left Auxiliary input
  • Red RCA - Right Auxiliary input
  • Green/Purple - (+) Reverse trigger
  • Green - Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White - Left Front Speaker (+)
  • White with Black Stripe - Left Front Speaker (-)
  • Purple - Right Rear Speaker (+)
  • Purple with Black Stripe - Right Rear Speaker (-)
  • Gray - Right Front Speaker (+)
  • Gray with Black Stripe - Right Front Speaker (-)
  • White RCA - Left Subwoofer signal
  • Red RCA - Center Channel signal (Note: If this jack is not present on the aftermarket radio, just leave be. Only the center channel speaker will be lost.)
    Fitments: Volvo
    • 2013 - 2016 Escape
    • 2012 - 2014 Focus
    • 2019 - and Up Ranger
    • 2014 - 2016 Transit Connect
More Information
Manufacturer Axxess
Part Number AXDIS-VL32
Integration Module Radio Replacement and Steering Wheel
Wiring harness function Replace Factory Radio
Steering Wheel Control No
Speaker level inputs Yes
Warranty 1 Year
Vehicle Year 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014
Vehicle Brand Volvo
Vehicle Model XC90
UPC Code 086429384709
Return period 30 days
Exchange period 30 days
