DISCONTINUED - Image Dynamics Q450.4 400W RMS, 4-Channel Class A/B High Fidelity Q Series Car Amplifier

DISCONTINUED - Image Dynamics Q450.4 400W RMS, 4-Channel Class A/B High Fidelity Q Series Car Amplifier

Image Dynamics 4 Channel Car Audio Amplifier

More Views

Image Dynamics
Ships Free!

Overall Rating 0 (Based on 0 reviews)

Image Dynamics Q450.4 Product Highlights

  • Optically Isolated MOSFET Power Supply
  • Bridgeable Capability
  • Nickel-Plated RCA Level Inputs
  • 4/3/2 Channel Operation
Expert Advice is a phone call away

Expert Knowledge

Talk to a specialist

Frequently Bought Together

Overview

Unit includes: Car audio amplifier, Mounting hardware, and Instruction manual

Image Dynamics Q450.4 400W RMS, 4-Channel Class A/B High Fidelity Q Series Car Amplifier Features:
  • Q Series 4-Channel Class A/B Car Amplifier
  • RMS Power Rating (14.4V):
  • 4 ohms: 75 watts x 4 chan.
  • 2 ohms: 100 watts x 4 chan.
  • Bridged, 4 ohms: 200 watts x 2 chan.
  • Optically isolated MOSFET power supply
  • LED power indicator
  • Fixed Bass Boost (+12 dB bass boost at 40 Hz)
  • Soft Start Turn-on
  • 4/3/2 Channel operation
  • Bridgeable Capability
  • Band pass crossover on front channels
  • Bi-Polar High-current output devices
  • Auxiliary full range output
  • Two-layer PC Board with heavy 2 oz copper
  • Massive ground planes and precision caps
  • 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heatsink for extreme heat dissipation
  • Nickel-plated RCA level inputs
  • Nickel-plated screw terminals
  • Input sensitivity:
  • Low level: 150mV-5V
  • Variable low-pass filter (50-5000 Hz, 12 dB/octave)
  • Damping factor: >100
  • In-line fuse requirement: 80 amps
  • Frequency response: 10-30,000 Hz
  • Signal-to-Noise ratio: 100dB
  • Dimensions: 13.0"L x 8-1/2"W x 2-1/4"H
  • 8-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Technical Specifications

Manufacturer Image Dynamics
Part Number Q450.4
Amplifier Topology Class Class AB
Number of Channels 4 Channel
Total Peak Power Output 500 watts
Total RMS Power Output 400 watts
Amplifier Bridging Bridgable @ 2 ohms
Minimum Impedance in Bridged Mode 4 ohm
Minimum Impedance in Un-Bridged Mode 2 ohm
Strappable Amplifier No
Strappable Power Output No
RCA Pre-amp Audio inputs N/A
RCA Pre-amp Audio outputs No
Preamp voltage 6 volts
Speaker level inputs No
Gain Control Yes
Bass Knob / Remote Gain No
Built in Crossover Band-pass, High-pass, Low-pass
Cooling Fan No
Color Black
Warranty 1 Year
Recommended Power Wire Gauge No
UPC Code No
