JVC KD-X270BT Single DIN Bluetooth Digital Media Receiver
Expert Knowledge
Talk to a specialist
- Single-DIN in-dash Digital Media receiver
- Built-in Bluetooth
- Blue Button, White LCD Illumination
- Built-In MOSFET 50W x 4 Amplifier
- iPhone and Android Pandora support
- 1 set of 4 volt RCA outputs
- 2 Phones Full-Time Connection
- Front USB connection
- Front 3.5mm Audio connection
JVC KD-X270BT Single DIN Bluetooth Digital Media Receiver
- Features:
- Single DIN In-Dash Digital Media receiver
- Full detachable face-plate for extra security
- 2-Line VA(Vertical Alignment) LCD Display with animation effects
- Blue Button, White LCD Illumination
- Front USB connection
- Built in Bluetooth with A2DP for wireless audio streaming
- 2 Phones Full-Time Connection
- iPhone®/Android™ Bluetooth Automatic Pairing
- Android Open Accessory Protocol (AOA2) and Android™ Music Playback via USB
- AM/FM radio tuner
- Spanish Text Display Compatible
- JVC Streaming DJ: Connect up to 5 Bluetooth devices simultaneously
- Voice control for iphone, tell your car stereo who to call or what station to listen to
- iPod and iPhone control with standard USB to lightning interface cable, simply connect your iPhone or iPod touch and access your entire music library
- Power Output: 4 channels x 50 watts peak and 4 channels x 22 watts RMS
- MP3, AAC, WAV, WMA & FLAC playback from USB
- Displays MP3 ID3 Tag including title, artist & album
- Easily accessible with wireless remote and graphic touch screen
- Pandora, iHeart Radio and Spotify control
- JVC Remote app control
- K2 Technology for Enhanced Digital Sound Quality
- Audio features:
- Plays MP3, ACC, WAC, WMA and FLAC
- Controls: Volume, Fader, Bass, Treble, Balance
- 13-band customizable Graphic equalizer with 9 presets
- Variable subwoofer level control with selectable Low-Pass and High-Pass digital crossover filter
- Time Alignment
- Space Enhancement
- Sound Response
- Sound Lift
- Volume Lift EQ
- Time Alignment
- MP3 ID3 tag information, display artist and song information
- 24-bit Digital Analog Converter (DAC) to enhance your MP3/WMA playback
- Loudness, Bass Boost, drvnEQ
- Tuner features:
- Includes AM & FM tuner with 24 preset stations memory
- Best Station Memory (BSM)
- RDS (Radio data service) Tuner
- Bluetooth features:
- Integral Bluetooth technology facilitates convenient hands-free phone calls and supports A2DP & AVRCP
- A2DP: Advanced Audio Distribution Profile allows high quality audio to be streamed from an audio device to the car stereo
- AVRCP: Audio/Video Remote Control Profile supports basic remote control functions (play, pause, etc) via Bluetooth
- SPP: Serial Port Profile provides a wireless replacement for RS-232 based serial communications
- PBAP: Phone Book Access Profile allows the car stereo to display the name of the incoming caller, as well as access the contact list of the mobile phone directly from the car stereo
- HFP: Hands Free Profile allows a hands-free car kit to connect to a compatible mobile phone
- External microphone for optimal placement
- 2 Phones Full-Time Connection
- 5 BT-Audio Full-Time Connection
- Bluetooth 2.0+ certified
- Compatible with most Bluetooth phone that support Bluetooth 2.0 and above
- Inputs and outputs:
- 1 - 4V preamp outputs (front, rear orsubwoofer)
- 1 - USB front connection accepts up to a 32Gb
- 1 - Front 3.5mm Audio connection for connection to multiple devices
- 1 - Rear Bluetooth Microphone input
- 1 - Steering wheel control input requires ASWC steering wheel interface
- Dimensions:
- Single DIN chassis
- Dimensions: 7-3/16"W x 6-1/4"D x 2-1/8"H
| Manufacturer | JVC |
|---|---|
| Part Number | KD-X270BT |
| Chassis Size | Single DIN |
| Illumination color | Red |
| Faceplate features | Detachable face plate |
| Disc Playback | No |
| Built in Bluetooth | Built in Bluetooth |
| NFC (Near Field Communication) | No |
| HD Radio | No |
| Radio Data Service - RDS | Yes |
| Satellite Radio | No |
| Front mounted auxiliary input | 3.5 mm audio input |
| USB input | Yes |
| SD Card input | No |
| Audio Formats | AAC, FLAC, Mpeg-3, WAV, WMA |
| RCA Pre-amp Audio outputs | 1 Pair |
| Preamp voltage | 2 volts |
| Steering Wheel Control | No |
| Wireless Remote Control | No |
| Warranty | 1 Year |
| Return period | 30 days |
| Exchange period | 30 days |
