The Beuler AVS310 Smart RCA Video Switcher allows three composite video sources to share a single monitor or video input. Designed for multi-camera vehicle installations, the module automatically switches to the most recently detected active video source, making it ideal for integrating front, rear, and side cameras without manually changing inputs. Its compact 12-volt design features three RCA video inputs and one RCA video output for straightforward installation with compatible automotive cameras, monitors, and multimedia receivers. The AVS310 displays one connected source at a time and provides a convenient solution for expanding systems with only one available video input.

Features:

• Intelligible 3-Way video switcher for switching between two video source on a single screen via an auto switcher
• Cannot be used to display two sources at the same time
• Video 1 has input priority (A) - First priority and will override every other input
• Video 2 has input priority (B) - Power must be disabled to camera on Video Inputs 1 and 3
• Video 3 has input priority (C) - Power must be disabled to camera on Video Inputs 1 and 2
• Auto default to video 1 when signal is present and will switch to alternate video when signal is present
• Module requires 12 volt power
• Can be used for backup/front camera or video source switching

Inputs and Outputs
• 3 - Video inputs
• 1 - Positive trigger input
• 1 - Negative trigger input

How the unit functions

• If a video signal is present on Video 1 (Top priority) this will display as long as a signal is present even when a signal is present on Video 2 (Bottom priority)
• If a video signal is present on Video 2 (Bottom priority) this will display as long as a signal is present when no signal is present on Video 1 (Top priority)
• If a video signal is present on Video 3 (Last priority) this will display as long as a signal is present when no signal is present on Video 1 or Video 2 (Higher priorities)
• Switcher must have power, video will not display when power is not present to the switcher
