Sony XAV-AX8100 Single DIN Digital Receiver with 8.95" Adjustable Display, HDMI, Apple Carplay, Android Auto and Weblink
- Single DIN stereo with over-sized 8.95" display
- HDMI & USB Input
- Apple CarPlay and Android Auto
- Sturdy and adjustable mount works in three directions: Tilt, Depth and Height
- CEA Rated Dynamic Reality Amp 20W x 4 RMS
- Sirius XM Ready
- Includes Steering Wheel Control Harness and customization
- PCM / MP3 / WMA / AAC / FLAC Audio Playback via USB
- Siri and Google Eyes Free
- Built-in Bluetooth
- Dynamic Stage Organizer (DSO) technology
- Features
- Single DIN stereo with over-sized 8.95" display
- Full-color 8.95" Clear Resistive touchscreen display (800 × 480 resolution)
- Sturdy and adjustable mount works in three directions and allows flexible installation in a variety of vehicles
- Adjust the Tilt, Depth and Height
- Apple CarPlay and Android Auto™ make it easier than ever to use your smartphone's helpful features on the road
- Android Auto: Use Google Maps to get directions and traffic updates whenever you need them
- Apple Carplay: Tell Siri where you're going, and it will give you real-time directions as you drive
- *Does not support Wireless Apple Carplay or Android Auto*
- Single Rear USB
- HDMI Input
- Sirius XM Ready
- WebLink car connectivity for in-vehicle, smartphone experience
- CEA Rated High Power Amplifier: 20Wx4
- Navigation ready with Google Maps, Apple Maps and Waze
- No Disc Slot: Does not play CD's or DVD's***
- Double DIN display with Single DIN Chassis
- Weblink Ready: lightweight app delivery platform designed especially for in-vehicle use
- Rear camera ready for easy reversing with customizable guidelines that help you back up safely
- Create virtual speakers on your dashboard with the Dynamic Stage Organizer
- Sony Quick Wake Up, instant boot after first, initial boot
- Includes Steering Wheel Control harness and customization
- White button illumination
- Android Auto features:
- Works via USB connection only
- Built in Navigation via Google Maps and Waze
- Navigation provides real-time traffic
- Hands-free voice guidance with text to speech prompts, so one can keep their eye on road while driving
- Place and receive hands-free calls using Google Assistant
- Place and receive hands-free text messages using Google Assistant
- Compatible with third party apps for a complete hands free assistant
- Apple Car Play features:
- Works via USB connection only
- Built in Navigation via Apple Maps and Waze
- Navigation provides real-time traffic
- Hands-free voice guidance with text to speech prompts, so one can keep their eye on road while driving
- Place and receive hands-free calls using Siri Assistant
- Place and receive hands-free text messages using Siri Assistant
- Compatible with third party apps for a complete hands free assistant
- Audio Features
- CEA Rated Dynamic Reality Amp 20W x 4 RMS
- 10-Band Customizable Graphic Equalizer
- EXTRA BASS Filter
- Dynamic Stage Organizer (DSO) technology helps overcome the acoustic problems caused by full range speakers mounted in the door
- High-Pass filter with variable slopes and crossover frequencies
- Variable subwoofer level control with selectable Low-Pass digital crossover filter
- 3 RCA Preouts
- Media Playback
- PCM / MP3 / WMA / AAC / FLAC Audio Playback via USB
- MPEG4-SP / AVC (H.264 Baseline) / WMV / FLV / MKV / XviD Video Playback via USB
- MP3 ID3 Tag Display (Title/Artist/Album)
- Tuner features:
- AM/FM RDS tuner with 18FM/12AM presets
- RDS (Radio data service) Tuner
- SiriusXM radio ready with SXV300 Sirius XM tuner
- Inputs and Outputs
- 2 - Pairs of 5V preamp outputs for Front and Rear
- 1 - 5V preamp output for Subwoofer
- 1 - USB Input
- 1 - HDMI Input
- 1 - Bluetooth Microphone Input
- 1 - Backup camera input
- 1 - Radio Antenna input
- 1 - Steering wheel control input (includes SWC harness)
- Sony WebLink:
- In-dash control of select apps via USB connection via iPhone or Android
- WebLink car connectivity solution offers the fastest and easiest way for drivers to elevate their in-vehicle, smartphone experience
- Display and get control apps like Youtube, Yelp, Weather, etc. onto the stereo
- Bluetooth
- Built-in Bluetooth technology for hands-free talking and audio streaming
- Supports SMS message notifications and A2DP audio streaming
- 6 speed dial memory banks; Recent call lists up to 20 numbers
- Hands-Free Profile (HFP)
- Advanced Audio Distribution Profile (A2DP)
- Audio/Video Remote Control Profile (AVRCP)
- Works with most Bluetooth enabled cell phones
- Includes a (external wired microphone for clear, convenient, distortion-free talking
- Maximum communication rage: 32.8 feet (approx, line of sight)
- Dimensions:
- Single DIN chassis, Double DIN Display
- Chassis Dimensions: 7"W x 7-1/8"D x 3-15/16"H
- Display Dimensions: 5-1/4"W x 1-1/2"D x 8-15/16"H
Manufacturer | Sony |
---|---|
Part Number | XAV-AX8100 |
Chassis Size | Single DIN |
Faceplate features | Detachable face plate |
RCA Pre-amp Audio outputs | 3 Pairs (Front, Rear, Sub) |
Preamp voltage | 5 volts |
LCD Screen Size | 9 inch - 10 inch |
Illumination color | Full Color |
LCD Screen Brightness | 350 Nit |
Touchscreen | Yes |
Widescreen Display | 16:9 Widescreen Display |
Native Screen Resolution | 800 x 480 |
Camera Inputs | 1-Camera Input |
Front camera input | No |
Back up camera input | Yes |
Parking grid lines | Adjustable |
Audio Video inputs | 1 Audio Video Input |
Front mounted auxiliary input | None |
Audio Video Outputs | None |
Built-in DVD Player | No |
Disc Playback | No |
Dual Zone Control | No |
SD Card input | No |
USB input | Yes |
HDMI input | Yes |
HDMI output | No |
Smartphone Compatible | Yes |
Smartphone Technology | Apple CarPlay and Android Auto |
Built in Phone Mirroring | No |
Amazon Alexa | No |
Time Alignment | Yes |
Built in Crossover | High-pass, Low-pass |
Audio Formats | AAC, FLAC, Mpeg-3, WAV, WMA |
Video Formats | H.264, MKV, MPEG-4, WMV, Xvid |
Built in Bluetooth | Built in Bluetooth |
NFC (Near Field Communication) | No |
HD Radio | No |
Radio Data Service - RDS | Yes |
Satellite Radio | Sirius XM Ready |
Navigation | via Smartphone |
Steering Wheel Control | Yes, requires external module |
Wireless Remote Control | Yes |
Operation Voltage | 12-15 Volt DC |
CEA2006 Compliant | No |
Warranty | 1 Year |
UPC Code | 027242922211 |
Return period | 30 days |
Exchange period | 30 days |
Our testing and analysis of the Sony XAV-AX8100
Sony sent us their brand new XAV-AX8100 single din digital media receiver, which is an update to the XAV-AX8000. But what exactly did they change, is it better than its predecessor and with a cost at $650, is it worth a purchase?
What's inside the box
Inside the box is an user manual, installation caution, 3 year warranty card, 8.95” capacitive touchscreen display with adjustable mount which will connect to the chassis and features a rear USB input and bottom HDMI input, wiring harness, two USB extensions one long one short, steering wheel control harness, velcro strap, external microphone for hands free calling and voice recognition, hardware, wireless remote control, rear display and mounting covers, and single din chassis.
Rear Connections
The rear connections include radio antenna, 5V RCA pre-amp outputs for front rear and subwoofer, microphone input, SWC input, wiring harness for power ground and speaker, and Sirius XM.
Adjustable Mount
One of the best features of the AX8100 is its adjustable mount, which requires only a screwdriver and can be done in minutes. This comes in handy in vehicles that may have protruding dashboards to help give you the best view of the screen possible. The display and actual chassis come separately, but connect with a ribbon cable input, simply slide the display into place at the front of the chassis. The various positions guarantee universal fitment in any dash. There are three tilt angle positions, three depth positions, and seven height positions. Of all the mounts we’ve tested, Sony’s are the most well built.
To reiterate, this is a single din stereo, it will not work in a double din opening unless your vehicle has a compatible single din Metra dash kit. For example, a 2016 Toyota Corolla can accommodate either a double din or single din stereo with the proper dash kit. Do your research before purchasing this.
Display
Once turned on, you can get a good look at the 8.95” anti-glare display, which not only is vibrant and sharp, but also holds up really well with a light pointed on it. I’ve always loved the displays of the Sony XAV-AX models, they’re sleek and modern, and although some people prefer variable color button illumination, I’m totally fine with just white. However, it has two major cons, it’s not HD, instead it’s 800 x480, nor is it a capacitive touchscreen, which are two massive balls that Sony dropped. The measurements of the display are 8-15/16” in width and 5-1/4” in height.
HDMI Input
The one new addition with this model is the inclusion of an HDMI input on the bottom rear of the display.
Apple Carplay and Android Auto
Apple Carplay and Android Auto are this headunits best features, however it is not compatible with Wireless Apple Carplay or Wireless Android Auto. Both apps integrate your message, audio and navigation apps from your device to the headunit. Video apps don't transfer.
Bluetooth
Bluetooth allows hands free calling and wireless music streaming.
USB Audio/Video/JPEG Playback
A USB thumb drive will play back music and video files. For audio it is compatible with PCM, MP3, WMA, AAC, and FLAC files. For video it is compatible with MPEG4-SP, AVC H.264, WMV, FLV, MKV, and XviD. You can also upload or view JPEG images on this stereo.
Weblink
The XAV-AX8100 also has Weblink source, which is a built-in app portal that gives you a screen mirroring option plus access to Waze, Youtube, internal music and internal videos on your phone. You must download the Weblink app on your phone to use this feature. However, it is still pretty damn slow and I wouldn’t see myself ever using it.
XAV-AX5600 Testing
Two channels driven, 4 ohm, 1 KHz, 14.4v
HP8903B Audio Analyzer: Volume 35, 20.16W RMS per channel, 0.17% distortion and 8.9 volts of output.
AMM-1: 15 Watts
Current draw: 4.91 amps
Two channels driven, 4 ohm, 40 Hz, 14.4v
HP8903B Audio Analyzer: Volume 35, 19.58W RMS per channel, 0.1% distortion and 8.78 volts of output.
AMM-1: 17 Watts
Current draw: 4.91 amps
RCA Testing, 40 Hz, 14.4v
HP8903B Audio Analyzer: Volume 48, 5.10 volts output
Distortion: 0.09
RCA Testing, 1 KHz, 14.4v
HP8903B Audio Analyzer: Volume 48, 5.17 volts output
Distortion: 0.08
