Quality Mobile Video WL-2CH-01 12V - 24V Wireless RF Remote Control Relay Switch 2-Channel Receiver with 2 FCC ID Transmitters
$26.99
In stock
SKU
WL-2CH-01
Expert Knowledge
Talk to a specialist
- 2CH Wireless RF Remote Control Switch Transmitter
- Two independent relay channels can either work together (in latching) for polarity reversing or individually (in pulse / hold) to control different electronics
- 3-Level efficient switching power supply system
- Firing Range: 100 meter(open) in theory, 15%-30% in reality
- Encoding Type: Fixed code
- Water resistant IP23 plastic housing
Unit includes: 12 volt relay transmitter, 2 wireless remotes
Quality Mobile Video WL-2CH-01 12V - 24V Wireless RF Remote Control Relay Switch 2-Channel Receiver with 2 FCC ID Transmitters
Quality Mobile Video WL-2CH-01 12V - 24V Wireless RF Remote Control Relay Switch 2-Channel Receiver with 2 FCC ID Transmitters
-
Features:
- 2CH Wireless RF Remote Control Switch Transmitter
- Rolling code key fob device offers better security and far more code combinations (more than 18 quintillion – 18 x 10^18 possibilities
- Two independent relay channels can either work together (in latching) for polarity reversing or individually (in pulse / hold) to control different electronics
- Control different electronics, such as one channel for garage door controller unit, the other for entry lights
- Easy programming & easy to use DIP switches working mode selection between pulse / momentary, hold / toggle and latching mode
- Designed to work both indoor and outdoor, default enclosure supplied protects the inner radio receiver circuit board safe from rain or other tough weather
- 3-Level efficient switching power supply system
- Each relay can switch up to 10A@14V DC or 10A@125V AC contact
- Built-in DC motor / solenoid polarity reversing control capability by using latching mode and both relays
- Used in anti-theft alarm control panels, home automation systems, short and long range turn devices on / off wirelessly, lifts, boats, marine, winches, motor-driven curtain, roller blinds, overhead garage door & gate barriers, motorcycles, vehicles, cars, truck, industrial and agricultural electrical control such as water pumps & sprayer, electric door release locks, windows, manual switches extender, LED lighting lamp bulbs and strips, entrance and access control etc.
- A-Grade printed circuit board
- SONGLE brand relay
- Enhanced internal copper wire antenna
- Microchip microprocessor
- PrincetonTech superheterodyne receiver unit
- One normally open limit switch for each relay
- 5V magic port for optional external buzzer
- Water resistant IP23 plastic housing
- Reinforced enclosure with mounting holes
- Light speed storage unit with maximum 400 transmitters memory
- Built-in DC motor polarity control
- Four independent relay output mode combinations include pulse, hold and latching
- Encoding Type: Fixed code
- Firing Range: 100 meter(open) in theory, 15%-30% in reality
- Programmable intelligent receiver
| Manufacturer | Quality Mobile Video |
|---|---|
| Part Number | WL-2CH-01 |
| Operation Voltage | 12-15 Volt DC |
| Relay type | Wireless remote control relay |
| Current capacity | 10 Amp |
| Wireless Remote Control | Yes |
| Wireless Transmission | Wireless connection |
| Warranty | 1 Year |
| Item Returns | This item can be returned |
