Beuler BU-5077-24R 24 Volt SPST 75-Amp High Current Relay
$39.99
In stock
SKU
BU-5077-24R
Expert Knowledge
Talk to a specialist
- High current relay
- 75 amp / 105 amp rated contacts
- SPST - Single Pole, Single Throw
- 24 Vdc rated coil with minimum 16 volt to trigger
- Direct replacement for Tyco V23232-D0001-X001
Unit includes: 24 volt relay
Beuler BU-5077-24R DPST 75-Amp High Current Relay
Beuler BU-5077-24R DPST 75-Amp High Current Relay
The Beuler BU-5077-24R is a high current 24 Volt relay that is designed for large loads. This relay is commonly used in automotive electrical and security installations. It easily switches 75 amps of current and peaks of 105 amps with minimal draw on the coil of 250 milliamps @ 12Vdc. It features dual plastic mounting tabs and a plastic housing. Dual Pole, Single throw for flexible installations and multiple uses such as accessory or electrical bus turn on.
-
Features:
- High current relay
- 75 amp / 105 amp rated contacts
- SPST - Single Pole, Single Throw
- 24 Vdc rated coil with minimum 16 volt to trigger
- Power consumption @ 12Vdc 260 mA
- Conventional 87, 30, 86, and 85 pin locations
- Compatible with most insulated and non insulated terminals and screw terminals
- Dimensions 2-7/8" (W) x 1-3/8" (D) x 2-1/8" (H) with terminals and tab
- Lifespan: 125,000 cycles @ 75 amps
- Lifespan: 100,000 cycles @ 100 amps
- Direct replacement for Tyco V23232-D0001-X001
| Manufacturer | Beuler |
|---|---|
| Part Number | BU-5077-24R |
| Operation Voltage | 24 Volt DC |
| Relay type | High Current |
| Current capacity | 75 Amp |
| Pole switching type | SPST (Single pole Single throw) |
| Tab type | Plastic Tab |
| Waterproof ingress protection | None |
| Warranty | 1 Year |
| California Proposition 65 |  Warning: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is [are] known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Return period | 30 days |
| Exchange period | 30 days |
